200kg Bottom Rolling Non Locking Sliding Door System 3m (40-56mm Doors)
£290.76
(£348.91 inc. VAT)
Availability: Item stocked in our warehouse
Quick Overview
For bottom rolling sliding wooden or metal doors weighing up to 200kg.
Max Panel Weight: 200kg
Max Door Height: 3000mm
Door Thickness Range: 40mm to 56mm
Max Door Width: 1500mm
No of Doors: 1
Kit Includes:
x1 3m Bronze Bottom Rail
x1 3m Polypropylene Channel
x2 Stainless Steel Door Stops
x2 2.4m Interlocking Profile
x2 Stainless Steel Twin Wheel Rollers
x2 Heavy Duty Stainless Steel Top Guides
NB: See related products for door locks, keeps and choice of handles. Door seals are not supplied but we recommend using a brush seal as per the related products.
Max Panel Weight: 200kg
Max Door Height: 3000mm
Door Thickness Range: 40mm to 56mm
Max Door Width: 1500mm
No of Doors: 1
Kit Includes:
x1 3m Bronze Bottom Rail
x1 3m Polypropylene Channel
x2 Stainless Steel Door Stops
x2 2.4m Interlocking Profile
x2 Stainless Steel Twin Wheel Rollers
x2 Heavy Duty Stainless Steel Top Guides
NB: See related products for door locks, keeps and choice of handles. Door seals are not supplied but we recommend using a brush seal as per the related products.
Description
Bottom rolling sliding door system ideal for bottom rolling patio doors and straight sliding room partitions for residential and commercial applications. The bottom rolling system allows heavy doors to be installed where there is insufficient support for a top hung system and therefore requires very little structural support. To cover the width of the opening, any number of doors can be used, on single or multiple lines of track. Doors can also slide to one or both sides of the opening. Door seals are not supplied. Doors must be constructed with bottom rails of at least 150mm depth to accommodate the concealed, morticed bottom rollers. Door weight is carried on the floor permitting the use of a light overhead structure.
