Concealed Overhead Door Closer Size 2-4

Arrone overhead concealed door closing device.

• Power size: EN 2 to EN 4, adjustable by spring tension
• Function: Closing, latching, cushion stop
• Cover: None
• Arm application: Door mount concealed push and pull
• Successfully type tested for conformity to all requirements of BS EN 1154:1997.
• Tested: Door width 1100mm, door weight 80kg
• Classification (door mount pull side): 3 | 8 | 4/2 | 1* | 1 | 3
• Classification (transom mount pull side): 3 | 8 | 4/2 | 1* | 1 | 3
• Fire tested to BS EN 1634-1: Suitable for 30, 60, 90 and 120 minute timber fire doors.
• Certification: CE AD5071, DOP HUK0026-UK. UKCA UK-AD7687, DOP HUK0026-UK. Certifire CF5181.

<p>The AR7383 can satisfy the opening force recommendations of BS 8300 and ADM when fitted to a door with minimum width of 777 mm (standard mount) and 796 mm (transom mount) according to third party data. However other installed hardware, door seals and differential air pressure will affect the products as fitted performance meaning that the door closer alone cannot allow compliance to BS 8300 and ADM.</p>

<p>The AR7383 series door closing device has been successfully fire tested with the use of an intumescent kit (AR/INT-7383). The supply and fitting of this intumescent kit is essential to the products compliance with the fire test evidence it has gained.</p>
