Dimensions
For doors: 1815mm to 2100mm & 2100-2300mm
If door size is 2300 - 2670mm please also order x1 of item 20775/4 & x1 of item 20775/5
45mm backset with a 20mm wide faceplate.
See diagram for dimensions.
Ideal solution for short doors.
Shorter doors can also be achieved but this would reduce the handle height.
Also known as Viper or Ventas.
Description
Non-handed locking mechanism with easily reversible centre latch to minimise stock requirements. Snib facility as standard on all locks.
Twin linear tapered bolts with an 18mm throw, lock into steel keeps offering resistance to forced entry.
Accepts standard 92mm handles and europrofile cylinders.
Tested to the latest security and performance standards the 2 Linear Bolt lock meets the requirements of PAS 24:2012.
The lock meets the requirements of BS EN 1670:2007 Grade 4 (240 hours) for Corrosion Resistance to provide the most robust finish and has also been performance tested in our to 50,000 cycles.
Comes with a 10 year mechanical guarantee.
