Exitex Oud Threshold - Various Finishes

Fitting Instructions: Remove bristle and rubber seals from aluminium sill section. Check width between inside faces of the door frame rebate and cut aluminium section to this size. (See Illustration) Cut the seals with scissors to the length of the aluminium and re-insert them into grooves in the sill. This sill requires an under door clearance of 24mm. If necessary, remove door and trim to allow for this ensuring bottom of door is smooth. Position the assembled sill between the door frame and mark fixing points through countersunk holes. Remove sill, drill fixing holes and insert plugs. Apply sealing compound to underside groove at front of sill. Ensure rubber seal at rear is in place and screw sill into place.
